Hertz HBD15-TMD 20 HP Belt-Driven Rotary Screw Air Compressor – Includes 120-Gallon Receiver Tank & Refrigerated Air Dryer (75 CFM @ 125 PSI)

Description

Hertz HBD 15 TMD Tank Mount Rotary Screw Air Compressor with Dryer

When you need serious air power in a compact, efficient, and reliable package, the Hertz HBD 15 TMD delivers beyond expectations. This heavy-duty 20 HP belt-driven rotary screw air compressor combines an ASME-certified 120-gallon air receiver and an integrated refrigerated air dryer, giving your business a complete, ready-to-run air system built for continuous operation. Designed for manufacturers, body shops, and industrial users who can’t afford downtime, the HBD 15 TMD provides clean, dry, and dependable air every single day.

Why You’ll Love It

• All-in-One Air Solution: Integrated refrigerated dryer and 120-gallon tank provide clean, dry air with no external setup—saving you space and installation costs.

• Powerful & Consistent Output: Delivers up to 75 CFM @ 125 PSI, with factory settings available for 100, 150, or 175 PSI to match your exact system requirements.

• Quiet Operation: Running at only 72 dB(A), the HBD 15 TMD packs industrial strength without disrupting your workspace.

• Engineered for Longevity: Features Hertz’s patented screw block, high-efficiency IE3 motor, and a rugged belt-drive design that ensures years of reliable service.

• Service Made Easy: Quick-release panels, spin-on air/oil separator, and simple belt-tensioning minimize maintenance time and maximize uptime.

• Confidence Built In: Optional 10-Year Airend Warranty backed by Hertz Kompressoren quality and the experts at Compressed Air Advisors Online.

Technical Specifications

• Model: Hertz HBD 15 TMD (Tank Mount with Dryer)

• Motor Power: 15 kW / 20 HP

• Capacity: 66–81 CFM (depending on pressure setting)

• Performance: 75 CFM @ 125 PSI

• Operating Pressure: 100 / 125 / 150 / 175 PSI (factory configurable)

• Air Receiver: 120-gallon ASME-rated tank

• Integrated Dryer: Refrigerated type, factory installed

• Noise Level: 72 dB(A)

• Dimensions (L × W × H): 74″ × 26″ × 63″

• Weight: 1,239 lbs

Built for Strength, Backed by Experts

At Compressed Air Advisors Online, we know your shop’s success depends on the quality of your air supply. That’s why we proudly carry Hertz Kompressoren, a global leader in compressor engineering. The HBD 15 TMD isn’t just a compressor—it’s a complete air solution that’s quiet, efficient, and ready to perform. Backed by our nationwide support and decades of industry experience, it’s the peace of mind your business deserves.
