Description

Chicago Pneumatic QRS 15D – 15 HP Rotary Screw Air Compressor with Dryer

Includes Refrigerated Dryer | 120-Gallon Tank | 54.9 ACFM @ 125 PSI
208–230/460V/3-Phase | Part Number: 4152023182

The Chicago Pneumatic QRS 15D is a fully integrated, high-capacity rotary screw air compressor designed for shops that require clean, dry, and reliable compressed air. Delivering 54.9 ACFM at 125 PSI, this 15 HP system features a factory-installed refrigerated dryer and a 120-gallon vertical ASME tank—giving you an all-in-one compressed air solution with exceptional efficiency and performance.

As part of the QRS 10–20 series, the QRS 15D is engineered for continuous duty, low maintenance, and ultra-quiet operation. It’s the perfect choice for fabrication facilities, automotive shops, body shops, CNC machining, manufacturing lines, and any operation where dry, steady, high-volume compressed air is essential.

---

Key Features & Benefits

Integrated Refrigerated Air Dryer

• Delivers clean, dry air to protect downstream tools, valves, and equipment.

• Prevents moisture-related issues such as corrosion, rust, and clogged lines.

• Fully integrated into the compressor package—no separate electrical or mounting required.

High-Volume Rotary Screw Performance

• Produces 54.9 ACFM @ 125 PSI, ideal for high-demand industrial applications.

• Pulse-free, energy-efficient rotary screw output improves tool performance and system reliability.

• Rated for 100% duty cycle—built for continuous operation.

120-Gallon ASME Receiver Tank

• Large tank stabilizes air pressure, reduces cycling, and increases overall system efficiency.

• Mounted and assembled for quick installation.

Ultra-Quiet, Shop-Friendly Operation

• Operates around 69 dB(A), allowing placement directly on the shop floor.

• Minimal vibration and sound thanks to its heavy-duty, insulated enclosure.

ES4000 Basic Controller

• Digital display monitors key parameters including temperature, pressure, run time, and service intervals.

• Intelligent shutdown and auto-restart enhance protection and uptime.

Tri-Voltage Electrical Compatibility

• Preconfigured for 208–230/460V/3-phase, simplifying electrical installation in industrial environments.

Built for Long-Term Reliability

• Precision-engineered oil-injected screw air end ensures long service life and high efficiency.

• Easy maintenance via spin-on oil filter and separator.

• Eligible for a 5-year extended warranty with authorized startup.

---

Technical Specifications

• Model: QRS 15D

• Horsepower: 15 HP

• ACFM: 54.9 @ 125 PSI

• Max Pressure: 125 PSI

• Tank Size: 120-Gallon ASME Vertical

• Dryer: Integrated Refrigerated Air Dryer

• Voltage: 208–230/460V/3Ph

• Noise Level: Approx. 69 dB(A)

• Part Number: 4152023182

---
