Description
Champion HR15-12 – 15 HP R-40 Two-Stage Reciprocating Air Compressor | 120-Gallon Horizontal Tank
Available Voltages: 208 V / 3 Ph, 230 V / 3 Ph, or 460 V / 3 Ph
CFM @ 175 PSI: 54.1 Pump RPM: 776
Tank Size: 120 Gallons Horizontal
Approx. Ship Weight: 1,210 lbs
Dimensions (L × W × H): 73″ × 36″ × 62″
Model: HR15-12 Compressor Pump: Champion R-40 Cast-Iron Two-Stage
Warranty: 1-Year Standard / 3-Year Pump (Option for 6-Year Extended with Premium Kit)
High-Volume Industrial Power with the Champion R-40 Pump
The Champion HR15-12 is a powerhouse 15 HP air compressor designed for continuous-duty performance in demanding industrial environments. Equipped with the Champion R-40 cast-iron two-stage pump, this unit delivers 54.1 CFM @ 175 PSI while operating at a low 776 RPM — providing cooler operation, reduced vibration, and extended service life.
Its 120-gallon ASME-certified horizontal tank provides ample air storage for steady pressure and reduced cycling, making it ideal for production lines, automotive facilities, and heavy-duty manufacturing applications that require reliable, high-volume air power.
R-40 vs. R-30 – The Next Level of Performance
Champion’s R-30 pump, used in standard 15 HP models, is an excellent industrial performer. However, the R-40 pump used on the HR15-12 takes it a step further.
It features larger cylinders and a longer stroke, allowing it to deliver more air (54.1 CFM vs. 48.7 CFM) while running at a slower 776 RPM instead of 1,034 RPM.
This design produces:
-
Lower operating temperatures
-
Reduced wear and noise levels
-
Longer bearing and component life
-
Improved efficiency and uptime
The R-40 is Champion’s premium-grade pump for users who demand superior output, efficiency, and long-term durability.
Key Features
-
R-40 Cast-Iron Two-Stage Pump: Larger displacement, low-RPM design for cooler, quieter operation.
-
120-Gallon ASME Horizontal Tank: Provides consistent air supply for high-demand applications.
-
Low-Speed Operation (776 RPM): Extends pump life and reduces vibration and wear.
-
Loadless Start Centrifugal Unloader: Protects the motor and ensures smooth startup.
-
Splash Lubrication System: Reliable, low-maintenance design for long-term service.
-
Three-Phase Power Only: Available in 208 V, 230 V, or 460 V for industrial applications.
-
Extended Warranty Option: Add Champion’s Premium Maintenance Kit for 6 years of pump coverage and 2 years on the full compressor package.
Performance Specifications
| Specification | HR15-12 |
|---|---|
| Horsepower | 15 HP |
| Pump Model | R-40 |
| Tank Capacity | 120 Gallons Horizontal |
| CFM @ 175 PSI | 54.1 |
| Pump RPM | 776 |
| Voltage | 208 / 3, 230 / 3, 460 / 3 |
| Weight | 1,210 lbs |
| Dimensions (L × W × H) | 73″ × 36″ × 62″ |
| Warranty | 1-Year Package / 3-Year Pump |
Why Buy from Compressed Air Advisors Online
At Compressed Air Advisors Online, we’re proud to be America’s choice for compressed air solutions—offering factory-authorized Champion compressors, expert advice, and nationwide delivery.
The HR15-12 gives you industrial-grade air power, a larger and slower R-40 pump, and the quality Champion is known for—backed by free freight and full factory warranty protection.
💨 Free Freight Across the Continental U.S.
🔧 Expert Guidance from Compressed Air Professionals
📦 Nationwide Delivery and Factory Warranty Support
The Champion HR15-12 — featuring the larger, low-RPM R-40 pump for 54.1 CFM @ 175 PSI, delivering superior performance and longevity for demanding industrial operations.
