Description
Champion HR10-12 Advantage Series – 10 HP Two-Stage Reciprocating Air Compressor | 120-Gallon Horizontal Tank
Available Voltages: 208 V / 3 Ph, 230 V / 3 Ph, or 460 V / 3 Ph
CFM @ 175 PSI: 33.8
RPM: 718
Tank Size: 120-Gallon Horizontal
Model: HR10-12
Compressor Pump: R-30D
Warranty: 1-Year Standard / 3-Year Pump Warranty (Option for 6-Year Extended with Premium Kit)
Fully Equipped. Factory Assembled. Ready to Run.
The Champion HR10-12 Advantage Series combines high output, heavy-duty performance, and plug-and-play convenience in one complete package. This 10 HP, two-stage, splash-lubricated compressor produces 33.8 CFM @ 175 PSI, providing the air capacity needed for automotive, manufacturing, and industrial operations that rely on consistent, high-pressure air.
Every Advantage Series unit is factory assembled, tested, and equipped with premium accessories to save time and installation cost. Designed for maximum reliability and easy maintenance, the HR10-12 Advantage offers true industrial durability backed by Champion’s legendary performance and support.
Key Features
-
R-30D Cast-Iron Pump: Four-cylinder, two-stage compressor pump engineered for cooler operation, maximum efficiency, and extended service life.
-
Factory-Installed Premium Accessories: Includes air-cooled aftercooler, automatic electric tank drain, low-oil stop control, mounted control panel, and vibration isolator pads.
-
Loadless Start Centrifugal Unloader: Reduces starting load on the motor for smoother, more reliable startups.
-
Splash Lubrication System: Proven lubrication design for dependable operation and low maintenance.
-
ASME-Certified 120-Gallon Horizontal Tank: Heavy-duty receiver equipped with drain, service, and relief valves for safe, long-term performance.
-
Voltage Options: Available in 208 V / 3 Ph, 230 V / 3 Ph, or 460 V / 3 Ph.
-
Extended Warranty Option: Champion Premium Maintenance Kit doubles coverage to 6 years on the pump and 2 years on the package.
Performance Specifications
| Specification | HR10-12 |
|---|---|
| Horsepower | 10 HP |
| Pump Model | R-30D |
| Tank | 120-Gallon Horizontal |
| CFM @ 175 PSI | 33.8 |
| RPM | 718 |
| Voltage | 208 V / 3 Ph, 230 V / 3 Ph, 460 V / 3 Ph |
| Weight | 895 lbs |
| Dimensions (L × W × H) | 71″ × 32″ × 55″ |
| Warranty | 1-Year Package / 3-Year Pump |
Why Buy from Compressed Air Advisors Online
At Compressed Air Advisors Online, we’re proud to be America’s choice for compressed air solutions—offering factory-authorized Champion compressors, nationwide delivery, and expert product guidance. Whether upgrading your existing system or expanding capacity, our team ensures you get the right solution, backed by free freight and factory warranty support.
💨 Free Freight Across the Continental U.S.
🔧 Expert Guidance from Compressed Air Professionals
📦 Nationwide Delivery and Factory Warranty Support
The Champion HR10-12 Advantage Series — industrial strength, factory equipped, and built to power your operation for years to come.
