Super-Dry D4 Desiccant Compressed Air Dryer – 300 SCFM Capacity with 3″ NPT Connections

Description

Super-Dry D-4 Desiccant Air Dryer – 3″ NPT, 300 SCFM

Premium Point-of-Use Drying Power—Clean, Dry Air Where You Need It Most

Looking for a rugged, high-capacity desiccant air dryer that delivers dependable moisture control at the point of use? The Super-Dry D-4 Desiccant Air Dryer is engineered to perform in demanding environments such as sandblasting, paint spraying, foam insulation, and more. With a robust 300 SCFM flow rate and 3″ NPT inlet/outlet ports, the D-4 model is ideal for applications requiring clean, dry compressed air without sacrificing flow or reliability.

🔧 Key Performance Specs:

• Inlet/Outlet Ports: 3″ NPT

• Airflow Capacity: 300 SCFM @ 100 PSIG

• Max Inlet Pressure: 150 PSI

• Max Inlet Temperature: 100°F (38°C)

• Unit Weight: 110 lbs

• Box Dimensions: 35″ x 13″ x 12″

---

✅ Features & Benefits:

• 3-Stage Drying System: Separation, filtration, and drying all in one unit—efficiently removes water, particulates, and oil aerosols from your air supply.

• Pre-filled Desiccant Cartridge: Ships ready to use with high-capacity activated alumina in a replaceable bag system—no mess, no downtime.

• Quick Maintenance: Stainless steel V-band clamp enables fast cartridge swaps without tools or hassle.

• Built Tough: Powder-coated, rust-free cast aluminum housing made in Canada with included wall-mount brackets.

• Enhanced Protection: Coalescer filters at the inlet and outlet eliminate desiccant dust and provide superior air purity.

• Safety First: Comes complete with pressure gauges, a ball valve, and safety relief valve pre-installed.

---

⚙️ Ideal Applications:

• Paint booths

• CNC and laser cutting

• Plasma and MIG/TIG welding

• Dust collectors

• Air tools and pneumatic equipment

• Foam spray and insulation setups

---

💡 Why Choose the D-4 from Super-Dry?

Built to outperform systems like the Devilbiss DAD 500 and Camair CT30, the D-4 offers industrial-grade drying power with minimal pressure drop and no air loss. Whether you’re supplementing a central system or protecting critical equipment at a workstation, the Super-Dry D-4 delivers dry air where it counts.

Backed by a 10-year warranty and designed with a 25-year life expectancy, this is the last point-of-use dryer you’ll need for years to come.

📦 Ready to Ship from Compressed Air Advisors Online — America’s Choice for Compressed Air Solutions.

*Moisture/Temperature Gauge not included.
