KBT2 Replacement Internal Battery Kit for Portable Devices

Description

Introduction

With the KBT2 installed, the K2 becomes the ultimate all-band field radio. Rated at 2.9 AH, the gel-cel battery is extremely safe, and can be recharged inside the K2 continuously from the same DC supply used to power the rig at home. Power outage? No problem–you’ll never miss a beat! (KBT2 not available for K2/100.)

Specs

SPECS

Battery (Battery not included in model KBT2-X.)

• Type: PowerSonic PS-1229, 2.9 AH sealed rechargeable lead-acid
• Dimensions: 7.01 x 1.34 x 2.52 inches (178 x 34 x 64 mm)
• Life: >5 years (standby/float service, with occasional full discharge)
• Temp. range: –10 to 50° C (14 to 122° F)

Charging Requirements

• Voltage: 13.8-14.2 VDC measured at K2’s DC power jack (J3)
• Time: 12-16 hours typ. depending on discharge condition

Operating Time

• Receive-only: >20 hours (receive current = 150 mA or less)
• Transceive: 6-12 hours typ. (150 mA receive, 5 W transmit, transmit duty cycle 20%)

Weight: 2.5 lbs. (1.1 kg) including battery, bracket, and all components

Manuals

MANUALS

• K2 Options and Accessories Manuals
