Kat2 20W Internal Automatic Antenna Tuner

Description

Introduction

KAT2 Automatic Antenna Tuner
The KAT2 allows you to connect nearly any antenna directly to the K2 and use it on all bands (160-10 m). Two antenna jacks are provided–instantly A/B test both antennas on any signal using the ANT 1/2 switch. Uses all latching relays, so current drain is zero except when tuning.

Specs

SPECS

• L – C Ranges: L: approx. 0-20 µH in 256 steps; C: approx. 0-2400 pF in 256 steps
• Network Type: L-network (series L, shunt C); C switchable to transceiver or antenna side
• SWR Range Matched: Up to 10:1 typ. (varies with band; smaller range on lowest/highest bands)
• Tuning time: 1 to 5 seconds typical for initial tune-up; < 1/2 sec. to recall stored settings
• SWR Display: 1.0:1 to 9.9:1
• Power Display: 0-20 watts (approx.); forward and reflected power shown in 0.1-w increments
• Current Drain: Approx. 10-30 mA during TUNE; < 5 mA at all other times
• Size: 4.2″ (L) x 1.6″ (D) x 1.5″ (H) (10.7 x 4.0 x 3.8 cm)

Manuals

MANUALS

• K2 Options Manuals
• K2 Options Mods and Notes
