Description
Overall Height @ deepest Side 4 5/8″
2007.5 and up Dodge trucks with 6.7L Diesel
This Pan will also work on #45RFE / 545RFE if there is no cross over exhaust pipe or the cross member interferes. Also this can be used if exhaust is relocated or changed to dual exhaust.
3 to 4 Quarts more than stock
*Gasket Seal, with o-ring sealed magnetic Drain Plug.
Includes: Bolt kit, and Drain Plug.
Heavy Duty differential covers and transmission pans provide increased lubricant and cooling capacity for hard working recreational and service vehicles. Mag-Hytec covers and pans set your vehicle apart in both aesthetics and function – cast in A356-T6 aluminum and texture powder coated black with machined cooling fins. Magnetic drain plugs trap worn gear material promoting fluid integrity. Each unit is fitted with ARP 568 O-rings for superior sealing. All hardware is 303 stainless steel, in most applications no gasket or sealant is required, and all Mag-Hytec parts are covered by a lifetime limited warranty. Depend on Mag-Hytec when you’re pulling a heavy load.
Avoid costly reapirs – Extend the life of your Vehicle – Expand oil Capacity – Runs Cooler, Lasts Longer
• Deep high-capacity sump for maximum cooling
• Magnetic drain plug
• 303 hardware except allen head cap screws are zinc plated
• 1/8 NPT temperature sender port
• Finned aircraft aluminum construction
• Requires only three allen key wrenches (included) for installation and service
• O-rings require no gaskets or sealants*
| Weight | 15 lbs |
|---|---|
| Dimensions | 17 x 13.5 x 5 in |
| 1/2, 3/4, or 1 Ton or Higher |
1 Ton or Higher, 3/4 |
| 4X2 / 4X4 |
4X2, 4X4 |
| Auto / Stick |
Automatic |
| Diesel / Gas |
Diesel, Gas |
| Single or Dual Rear Tires |
DRW, SRW |
| Truck, Van, Motorhome |
Truck |
