High-Pressure Brake Hose Assembly – 302 Series, -4 AN, 12 Inch, 1/8″ Outlet

Description

Piper Brake Cylinder Hose for the following aircraft:

HAND BRAKE ONLY (No Toe Brakes):

From Hand Brake to RH Cylinder Bottom Tee

PA28-140, S/N 28-20002 & UP

PA28-150/160/180, S/N 28-251 & UP;

PA28-151/161/181;

PA28-235, S/N 28-10003 & UP.

SINGLE AND BOTH SIDE TOE BRAKES:

From Hand Brake to LH Cylinder Bottom Tee & LH/RH Top to Both Brakes Line.

PA28-140, S/N 28-20002 thru 28-7325684;

PA28-150/160/180; S/N 28-1 thru 28-7305611;

PA28-235; S/N 28-10003 thru 28-73101187;

PA29R-180; S/N 28R-30005 thru 28R-7130019;

PA28R-200; S/N 28R-30482, 28R-35001 thru 28R-7335455;

PA28R-201: ALL;

PA32-260; S/N 32-7400001 & UP;

PA32-300; S/N 32-7440001 & UP;

PA32-300R; S/N ALL;

PA32(R)-301; ALL;

PA34-200; S/N 34-7250001 thru 34-7450220.

IF YOU REQUIRE FAA FORM 8130-3 – ORDER 63901-009.
