Description
Champion HR30-24 – 30 HP R-70 Two-Stage Reciprocating Air Compressor | 240-Gallon Horizontal Tank
Available Voltages: 208 V / 3 Ph, 230 V / 3 Ph, or 460 V / 3 Ph
CFM @ 175 PSI: 101.8 Pump RPM: 907
Tank Size: 240 Gallons Horizontal
Approx. Ship Weight: ≈ 2,050 lbs
Dimensions (L × W × H): 90″ × 36″ × 71″
Model: HR30-24 Compressor Pump: Champion R-70 Cast-Iron Two-Stage
Warranty: 1-Year Standard / 3-Year Pump (Option for 6-Year Extended with Premium Kit)
Champion’s Largest Single-Pump Horizontal Reciprocating System
The Champion HR30-24 is a powerhouse compressor designed for high-demand industrial applications where reliability, efficiency, and performance are critical.
Powered by the heavy-duty Champion R-70 cast-iron two-stage pump, this 30 HP compressor delivers 101.8 CFM @ 175 PSI at only 907 RPM, providing exceptional air output while maintaining cooler operation and long service life.
The 240-gallon ASME-certified horizontal tank offers significant air storage capacity, ensuring stable air pressure and fewer cycles in large-scale production, manufacturing, and fabrication environments.
The Champion R-70 Pump — Heavy-Duty Performance for Continuous-Duty Applications
Champion’s R-70 pump is designed for 20–30 HP compressors and stands as one of the most efficient and durable two-stage compressor pumps in the industry.
With its cast-iron cylinders, oversized cooling fins, and balanced flywheel design, the R-70 ensures smooth, efficient compression and reduced operating temperatures.
Key R-70 Advantages:
-
High Capacity: 101.8 CFM @ 175 PSI for large industrial systems
-
Low-Speed Operation (907 RPM): Cooler, quieter performance and reduced wear
-
Rugged Cast-Iron Construction: Built to handle continuous-duty industrial workloads
-
Two-Stage Efficiency: Compresses air in two steps for maximum pressure and energy savings
This pump is the backbone of Champion’s top-end reciprocating line, delivering unmatched durability and reliability for 24/7 industrial operation.
Key Features
-
R-70 Cast-Iron Two-Stage Pump: High-output, low-RPM design for maximum efficiency and longevity.
-
240-Gallon ASME Horizontal Tank: Massive storage capacity for steady system pressure and reduced cycling.
-
Industrial-Grade Output: 101.8 CFM @ 175 PSI with smooth, quiet operation.
-
Low-Speed Performance: 907 RPM ensures cooler running and longer component life.
-
Loadless Start Centrifugal Unloader: Reduces motor strain and ensures smooth startup.
-
Splash Lubrication System: Proven, low-maintenance reliability.
-
Three-Phase Power Only: Available in 208 V, 230 V, or 460 V.
-
Extended Warranty Option: Add Champion’s Premium Maintenance Kit for 6 years of pump coverage and 2 years on the complete compressor package.
Performance Specifications
| Specification | HR30-24 |
|---|---|
| Horsepower | 30 HP |
| Pump Model | R-70 |
| Tank Capacity | 240 Gallons Horizontal |
| CFM @ 175 PSI | 101.8 |
| Pump RPM | 907 |
| Voltage | 208 / 3, 230 / 3, 460 / 3 |
| Dimensions (L × W × H) | 90″ × 36″ × 71″ |
| Weight | ≈ 2,050 lbs |
| Warranty | 1-Year Package / 3-Year Pump |
Why Buy from Compressed Air Advisors Online
At Compressed Air Advisors Online, we’re proud to be America’s choice for compressed air solutions — offering factory-authorized Champion compressors, expert advice, and nationwide delivery.
The HR30-24 provides Champion’s largest single-pump output, combining the durable R-70 pump with a 240-gallon tank for unmatched reliability, capacity, and performance — backed by free freight and full factory warranty protection.
💨 Free Freight Across the Continental U.S.
🔧 Expert Guidance from Compressed Air Professionals
📦 Nationwide Delivery and Factory Warranty Support
The Champion HR30-24 — featuring the R-70 low-RPM pump delivering 101.8 CFM @ 175 PSI on a massive 240-gallon horizontal tank. Built for industrial strength, efficiency, and endurance.
