Champion HR10D-12 – Duplex 10 HP (2x R-30 Pumps) Two-Stage Reciprocating Air Compressor | 120-Gallon Horizontal Tank
Available Voltages: 208 V / 3 Ph, 230 V / 3 Ph, or 460 V / 3 Ph
CFM @ 175 PSI: 67.6 (33.8 × 2) Pump RPM: 718
Tank Size: 120 Gallons Horizontal
Approx. Ship Weight: 1,725 lbs
Dimensions (L × W × H): 83″ × 30″ × 56″
Model: HR10D-12 Compressor Pumps: (2) Champion R-30 Cast-Iron Two-Stage
Warranty: 1-Year Standard / 3-Year Pump (Option for 6-Year Extended with Premium Kit)
Double the Power. Industrial-Duty Redundancy. Proven Champion Reliability.
The Champion HR10D-12 is a duplex two-pump system designed for industrial users who demand high air capacity, redundancy, and nonstop reliability.
Equipped with two Champion R-30 cast-iron two-stage pumps, each driven by its own 10 HP motor, the HR10D-12 produces a total of 67.6 CFM @ 175 PSI while operating at a low 718 RPM per pump.
This heavy-duty system can run one pump at a time for alternating operation or both simultaneously for maximum air delivery—making it ideal for large manufacturing facilities, service centers, and production operations that rely on continuous compressed air.
Twin R-30 Pumps – Built to Run and Last
Each R-30 pump is precision-machined and built from solid cast iron to deliver years of dependable, low-speed performance.
The dual-pump configuration not only doubles air output but also provides built-in redundancy, allowing one side to operate while the other rests or undergoes maintenance.
This ensures continuous uptime and unmatched dependability, even in 24/7 operations.
Key Features
-
Dual R-30 Cast-Iron Pumps: Two slow-speed, two-stage pumps provide double capacity and reliability.
-
Duplex Control Panel: Alternating or simultaneous operation for flexible performance and maintenance management.
-
120-Gallon ASME Horizontal Tank: Heavy-duty tank provides stable storage and efficient air delivery.
-
Low-Speed Operation (718 RPM per pump): Ensures cooler operation and longer component life.
-
Loadless Start Centrifugal Unloaders: Reduce startup strain and motor wear.
-
Splash Lubrication System: Simple, proven lubrication for reliable performance.
-
Three-Phase Power Only: Available in 208 V, 230 V, or 460 V.
-
Extended Warranty Option: Add Champion’s Premium Maintenance Kit for 6 years of pump coverage and 2 years on the full package.
Performance Specifications
| Specification | HR10D-12 |
|---|---|
| Horsepower | (2) × 10 HP |
| Pump Model | (2) × R-30 |
| Tank Capacity | 120 Gallons Horizontal |
| Total CFM @ 175 PSI | 67.6 |
| Pump RPM | 718 |
| Voltage | 208 / 3, 230 / 3, 460 / 3 |
| Weight | 1,725 lbs |
| Dimensions (L × W × H) | 83″ × 30″ × 56″ |
| Warranty | 1-Year Package / 3-Year Pump |
Why Buy from Compressed Air Advisors Online
At Compressed Air Advisors Online, we’re proud to be America’s choice for compressed air solutions—offering factory-authorized Champion compressors, expert guidance, and nationwide delivery. The HR10D-12 is built for facilities that can’t afford downtime, providing redundant power, dual-pump reliability, and continuous-duty performance—backed by free freight and full factory warranty protection.
💨 Free Freight Across the Continental U.S.
🔧 Expert Guidance from Compressed Air Professionals
📦 Nationwide Delivery and Factory Warranty Support
The Champion HR10D-12 — featuring dual R-30 pumps delivering 67.6 CFM @ 175 PSI for dependable, continuous industrial performance with built-in redundancy.
