Champion BR7 7.5 HP Two-Stage Base-Mounted Reciprocating Air Compressor Featuring R30 Pump

Description

Champion BR7 – 7.5 HP Base Mounted Two-Stage Reciprocating Air Compressor | R-30 Pump

Available Voltages: 208 V / 1 Ph, 230 V / 1 Ph, 208 V / 3 Ph, 230 V / 3 Ph, or 460 V / 3 Ph
CFM @ 175 PSI: 25.6
Pump RPM: 570
Dimensions (L × W × H): 43″ × 23″ × 29″
Approx. Ship Weight: 430 lbs
Model: BR7
Compressor Pump: Champion R-30 Cast-Iron Two-Stage
Mounting: Base Mounted (No Tank)
Warranty: 1-Year Standard / 3-Year Pump (Option for 6-Year Extended with Premium Kit)

---

Industrial-Grade Power with the Legendary R-30 Pump

The Champion BR7 is a heavy-duty, base-mounted 7.5 HP compressor built for continuous-duty industrial use. At the heart of this machine is Champion’s R-30 two-stage cast-iron pump, running at a low 570 RPM to produce 25.6 CFM @ 175 PSI. The slower-speed operation results in cooler temperatures, reduced wear, greater efficiency, and a dramatically longer service life compared with smaller, high-RPM pumps.

The BR7’s base-mounted design makes it ideal for OEM applications, central air systems, or facilities with an existing receiver tank. Each unit is factory-assembled, tested, and proven reliable — ready to deliver years of dependable performance.

---

How the BR7 Differs from the BR7F

While both models share a 7.5 HP rating, the BR7 and BR7F use different pump assemblies that define their performance:

• BR7: Features the larger R-30 pump, producing 25.6 CFM @ 175 PSI at only 570 RPM.

  • Runs cooler and quieter with longer life and higher efficiency.

• BR7F: Uses the smaller R-15B pump, producing 22.3 CFM @ 175 PSI at 949 RPM.

  • Compact, higher-speed design suited for lighter-duty installations.

👉 If you’re comparing the two, the BR7 is the premium model—optimized for efficiency, durability, and lower operating costs.

---

Key Features

• Champion R-30 Pump: Low-RPM, high-output design for cooler operation and maximum service life.

• Base-Mounted Configuration: Perfect for integrating into an existing receiver or centralized system.

• Heavy-Duty Cast-Iron Construction: Ensures long-term durability and reliability under continuous load.

• Loadless Start Centrifugal Unloader: Reduces startup torque and protects motor components.

• Splash Lubrication System: Proven, low-maintenance design.

• Precision Balancing: Smooth operation with minimal vibration and noise.

• Multiple Voltage Options: Available in 208/1, 230/1, 208/3, 230/3, and 460/3 volt models.

• Extended Warranty Option: Champion Premium Maintenance Kit extends pump coverage to 6 years and the package to 2 years.  Click Here For Extended Warranty  Kit

---

Performance Specifications

Specification	BR7
Horsepower	7.5 HP
Pump Model	R-30
Mounting	Base Mounted
CFM @ 175 PSI	25.6
Pump RPM	570
Voltage	208 / 1, 230 / 1, 208 / 3, 230 / 3, 460 / 3
Weight	430 lbs
Dimensions (L × W × H)	43″ × 23″ × 29″
Warranty	1-Year Package / 3-Year Pump

---

Why Buy from Compressed Air Advisors Online

At Compressed Air Advisors Online, we’re proud to be America’s choice for compressed air solutions—offering factory-authorized Champion compressors, expert technical guidance, and nationwide delivery. Whether you’re upgrading, building redundancy, or integrating a base-mount system, we ensure you get the right equipment backed by free freight and factory warranty support.

💨 Free Freight Across the Continental U.S.
🔧 Expert Advice from Compressed Air Professionals
📦 Nationwide Delivery and Factory Warranty Support

---

The Champion BR7 — featuring the larger R-30 pump for cooler operation, more airflow, and a longer lifespan than the BR7F.
