Description
Champion VR5-8 Advantage Series – 5 HP Two-Stage Reciprocating Air Compressor | 80-Gallon Vertical Tank
Available Voltages: 208–230 V / 3 Ph, 230 V / 1 Ph, and 460 V / 3 Ph
CFM @ 175 PSI: 17.0
RPM: 737
Tank Size: 80-Gallon Vertical
Model: VR5-8
Compressor Pump: R-15B
Warranty: 1-Year Standard / 3-Year Pump Warranty (Option for 6-Year Extended with Premium Kit)
Fully Equipped. Factory Assembled. Ready to Work.
The Champion VR5-8 Advantage Series compressor provides professional-grade performance in a plug-and-play package. Designed for industrial and commercial use, this 5 HP, two-stage, splash-lubricated compressor delivers 17 CFM @ 175 PSI, making it perfect for body shops, manufacturing facilities, and woodworking operations that need reliable, high-pressure air every day.
The Advantage Series takes Champion’s proven R-Series design and adds factory-installed premium features that save time and protect your investment from day one — so your compressor arrives fully assembled, wired, and ready to run right out of the crate!
Key Features
-
R-15B Cast-Iron Pump: Heavy-duty, two-stage compressor head built for cooler operation and long service life.
-
Factory-Installed Accessories Included: automatic electric tank drain, low-oil stop control, mounted control panel, and vibration isolators come standard. Optional Air-cooled aftercooler,
-
Splash Lubrication System: Proven lubrication design for reliability and reduced maintenance.
-
ASME-Certified 80-Gallon Vertical Tank: Industrial-grade receiver with relief, drain, and service valves pre-installed.
-
Loadless Start System: Centrifugal unloader ensures smooth motor start-ups and less wear on components.
-
Flexible Voltage Options: Available in 208–230 V / 3 Ph, 230 V / 1 Ph, and 460 V / 3 Ph to fit any shop setup.
-
Extended Warranty Option: Champion’s Premium Maintenance Kit doubles coverage to 6 years on the pump and 2 years on the package. Click Here!
Performance Specifications
| Specification | VR5-8 |
|---|---|
| Horsepower | 5 HP |
| Pump Model | R-15B |
| Tank | 80-Gallon Vertical |
| CFM @ 175 PSI | 17.0 |
| RPM | 737 |
| Voltage | 208–230 V / 3 Ph, 230 V / 1 Ph, 460 V / 3 Ph |
| Weight | 590 lbs |
| Dimensions (L × W × H) | 35″ × 27″ × 75″ |
| Warranty | 1-Year Package / 3-Year Pump |
Why Buy from Compressed Air Advisors Online
At Compressed Air Advisors Online, we’re America’s choice for compressed air solutions — offering nationwide expertise, factory-authorized Champion equipment, and professional support before and after the sale. Our team helps you choose the right system for your needs and backs every purchase with expert guidance and free freight delivery.
💨 Free Freight Across the Continental U.S.
🔧 Expert Advice from Compressed Air Professionals
📦 Nationwide Delivery and Factory Warranty Support
The Champion VR5-8 Advantage Series — industrial-ready, fully equipped, and built to perform for decades.
