Airward Van RV-10 Reinforcing Ring Kit – Tunnel Access Doubler Assembly

Description

Use with RV-10, Inspection Cover, Tunnel Access;

Outside Dimensions: 12″ x 8 1/4″ – .040 Aluminum

Inside Dimensions: 10″ x 5 3/4″;

12 positions for Nutplates.

Kit includes:

1 – AW-RING(DOUBLER)INSPECTION12x81/4

12 – K1100-08 Anchor Nuts;

12 – MS24693S4 Screw, Machine – Countersunk;

11 – LP4-3 Rivet, Pull;

50 – AN426AD3-3-5 Rivet, Solid – Countersunk;

1 – Copy AirWard’s Installation Instructions with Photos.
